Product Details
Place of Origin: jiangsu, China
Brand Name: guanxiong
Certification: CE
Model Number: CT-32
Payment & Shipping Terms
Minimum Order Quantity: 1 pieces
Price: $140000/sets 1-99 sets
Delivery Time: 3-15 work days
Payment Terms: L/C, T/T
Supply Ability: 500 Set/Sets per Month
Application: |
Hospital |
Warranty: |
4 Year |
Power Source: |
Electric |
Product Name: |
CT Scan |
Sampling Rate: |
1800view/cycle |
Max FOV(field Of View): |
500mm |
Min Scan Time(s/360°): |
0.72s |
Slices: |
32 Slices |
Safety Standard: |
MOL |
Shelf Life: |
3 Years |
After-sale Service: |
Online Technical Support |
Aperture Of Frame: |
71.5cm |
Inclination Angle Of Frame: |
±30° |
Cooling Mode: |
Wind Cooling |
Application: |
Hospital |
Warranty: |
4 Year |
Power Source: |
Electric |
Product Name: |
CT Scan |
Sampling Rate: |
1800view/cycle |
Max FOV(field Of View): |
500mm |
Min Scan Time(s/360°): |
0.72s |
Slices: |
32 Slices |
Safety Standard: |
MOL |
Shelf Life: |
3 Years |
After-sale Service: |
Online Technical Support |
Aperture Of Frame: |
71.5cm |
Inclination Angle Of Frame: |
±30° |
Cooling Mode: |
Wind Cooling |
| Rack system | Aperture of frame | 71.5cm |
| Inclination angle of frame | ±30° | |
| Scanning collimation | 2x1.1mm 8x0.55mm 16x0.55mm 16x1.1mm 32x0.275mm |
|
| Sampling rate | 5400 view/360° | |
| Image collection | 32 floors/360° | |
| Fastest speed | 0.72 sec/lap | |
| Scanning visual field | 500mm | |
| Data transmission mode | digital transmission | |
| Cooling mode | wind cooling | |
| explorer | Number of detector rows | Row 24 |
| Number of detector units per row | 888 | |
| Total number of detector units | 21312 | |
| Detector width | 17.6mm | |
| Thinnest physical layer thickness | 0.55mm |
| X- ray system | focus | Large: 1.2mmx1.4mm Small: 0.7mmx0.8mm |
| Heat capacity of spherical tube | 3.5MHU | |
| Anode heat dissipation rate | 735KHU/min(8750W) | |
| Minimum output of bulb voltage | 60KV | |
| Bulb tube voltage range | 60KV/70KV/80KV/100KV/120KV/140KV | |
| Bulb tube current | 10mA-350mA | |
| High voltage generator power | 42KW | |
| Maximum continuous exposure time | 100seconds |
The precise tomographic technique
The thickness of the precision tomography images is only 0.275mm, both the inner ear structures such as the
ossicles and the cochlea, and the relationship between the inner ear structures are clearly visible, such as the
connection of the malleus and the corpora incudis.
The conventional tomographic inner ear image
Intelligent medical imaging workstation
According to DICOM 3.0 international standard, the self-developed CIW workstation completely complies with
standards of medical images, including functions of obtaining, processing, analyzing, managing, archiving
querying, browsing, printing standard image format output, report writing and so on.At the same time, CIW also
contains many other advanced clinical applications.
