Product Details
Place of Origin: Jiangsu, China
Brand Name: Healicom
Certification: CE
Model Number: HX50R-A
Payment & Shipping Terms
Minimum Order Quantity: 1 pieces
Price: $8,000.00 - $9,300.00/units
Packaging Details: wooden case
Delivery Time: 3-15 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 Unit/Units per Month
Power Source: |
Electricity |
Warranty: |
1 Year |
After-sale Service: |
Online Technical Support |
Material: |
Metal, Plastic, Steel |
Shelf Life: |
1years |
Quality Certification: |
Ce |
Instrument Classification: |
Class II |
Safety Standard: |
GB/T18830-2009 |
Output Power: |
50KW |
Power Voltage: |
380V±38V |
KV Range: |
40~150kV |
MA Range: |
10~630mA |
MAs Range: |
0.1 ~630mAs |
Exposure Time: |
0.002~6.3S |
X-ray Tube Small Focus: |
0.6 |
X-ray Tube Large Focus: |
1.2 |
X-ray Tube Anode Speed: |
3000r/min |
Wire Flat Panel Detector: |
17X17inch |
Port: |
Shanghai Ningbo Tianjin |
Power Source: |
Electricity |
Warranty: |
1 Year |
After-sale Service: |
Online Technical Support |
Material: |
Metal, Plastic, Steel |
Shelf Life: |
1years |
Quality Certification: |
Ce |
Instrument Classification: |
Class II |
Safety Standard: |
GB/T18830-2009 |
Output Power: |
50KW |
Power Voltage: |
380V±38V |
KV Range: |
40~150kV |
MA Range: |
10~630mA |
MAs Range: |
0.1 ~630mAs |
Exposure Time: |
0.002~6.3S |
X-ray Tube Small Focus: |
0.6 |
X-ray Tube Large Focus: |
1.2 |
X-ray Tube Anode Speed: |
3000r/min |
Wire Flat Panel Detector: |
17X17inch |
Port: |
Shanghai Ningbo Tianjin |
|
Technical Specifications
|
|
|
|
X-ray generator (include console)
|
|
|
|
Output Power
|
50KW
|
|
|
Power Voltage
|
380V±38V
|
|
|
kV range
|
40~150kV
|
|
|
mA range
|
10~630mA
|
|
|
mAs range
|
0.1 ~630mAs
|
|
|
Exposure time
|
0.002~6.3S
|
|
|
X-ray tube
|
|
|
|
Anode Heat Storage Capacity
|
240kHU
|
|
|
Small focus
|
0.6
|
|
|
Large focus
|
1.2
|
|
|
Anode speed
|
3000r/min
|
|
|
Collimator
|
|
|
|
Inherent filtration
|
1.0mm Al /75kV
|
|
|
Light Source
|
LED
|
|
|
Radiographic Table
|
|
|
|
Top Table Size
|
2100X800X650mm
|
|
|
Bucky Size
|
18X18inch
|
|
|
Table longitudinal movement
|
≥900mm
|
|
|
Cassette Movement Distance
|
≥500mm
|
|
|
Vertical Chest stand
|
|
|
|
Vertical moving range
|
≥1200mm
|
|
|
Bucky Size
|
18X18inch
|
|
|
Double Grid
|
|
|
|
Size
|
18X18inch
|
|
|
Ratio
|
1:1
|
|
|
F.D.
|
100cm
|
|
|
Density
|
40 L/cm
|
|
