Product Details
Place of Origin: jiangsu, China
Brand Name: guanxiong
Certification: CE
Model Number: YJF50DR-P
Payment & Shipping Terms
Minimum Order Quantity: 1 pieces
Price: $23000/sets 1-99 sets
Delivery Time: 3-15 work days
Payment Terms: L/C, T/T
Supply Ability: 500 Set/Sets per Month
Power Source: |
Electricity |
Warranty: |
1 Year |
After-sale Service: |
Online Technical Support |
Material: |
Metal |
Shelf Life: |
1years |
Quality Certification: |
CE ISO |
Instrument Classification: |
Class II |
Anode Speed: |
3000r/min |
Application: |
X-ray Room .Radiography Department |
KV Range:: |
40~150kV |
Screen: |
8' Button Screen |
Operating Frequency:: |
≥30kHz |
Inherent Filtration: |
1.0mm Al /75kV |
MA Range: |
10~630mA |
Exposure Time Range: |
0.002~6.3S |
Power Source: |
Electricity |
Warranty: |
1 Year |
After-sale Service: |
Online Technical Support |
Material: |
Metal |
Shelf Life: |
1years |
Quality Certification: |
CE ISO |
Instrument Classification: |
Class II |
Anode Speed: |
3000r/min |
Application: |
X-ray Room .Radiography Department |
KV Range:: |
40~150kV |
Screen: |
8' Button Screen |
Operating Frequency:: |
≥30kHz |
Inherent Filtration: |
1.0mm Al /75kV |
MA Range: |
10~630mA |
Exposure Time Range: |
0.002~6.3S |
| Main Component | Technical Spe | |
|
X-ray Generator (include console) |
Output Power | 50KW |
| Power Voltage | 380V±38V | |
| kV range | 40~150kV | |
| mA range | 10~630mA | |
| mAs range | 0.1 ~630mAs | |
| Exposure time | 0.002~6.3S | |
|
X-ray Tube |
Small focus | 0.6 |
| Large focus | 1.2 | |
| Anode speed | 3000r/min | |
|
Collimator |
Inherent filtration | 1.0mm Al /75kV |
| Light Source | LED | |
|
Radiographic Table
|
Top Table Size | 2100X800X650mm |
| Bucky Size | 18X18inch | |
| Table longitudinal movement | ≥900mm | |
| Cassette Movement Distance | ≥500mm | |
|
Vertical Chest Stand |
Vertical moving range | ≥1200mm |
| Bucky Size | 18X18inch | |
|
Wire Flat Panel Detector |
Size | 17X17inch |
| Scintillator | CSI | |
| Pixels | 3072*3072 | |
| Resolution | 3.6 | |
| AD Conversion | 16 | |
|
Computer& LCD |
CPU | ≥2.8GHz |
| Memory | ≥4GB | |
| Disk Capacity | ≥1T | |
| Medical LCD | 23inch | |
X-ray generator
Rich DR upgrade reserve interface
Fault self-diagnosis and protection
Automatic calibration of tube current
Infrared photoelectric switch for four-way table
X-ray tube has the function of filament dormancy
AEC function, different ionization chamber as optional
Analog - digital double - loop control, simple operation, high intelligence
High kV, high current, high power,strong penetration,able to handle obese patients
●Profession Acquisition Software
Support Multi-languages
Support professional tools
Support different brand of X-ray generators
Support RIS/PACS/DICOM Printer Connection
●Professional DR workstation
Image capture
Print and storage
Image post-processing
Patient manageme
●Applicable to orthopedics, emergency room, operating room, etc.,
As human head, limbs, chest, spine, lumbar spine for medical diagnosis
